100 node 12V Bullet WS2811 Pixels
Couldn't load pickup availability
A set of 100 bullet style, regulated 12V individually addressable WS2811 pixels, IP68 18 AWG Black wire, 13.5mm (Ray Wu Style) connectors
Specification:
Color |
full rgb color,24bit,256 gray scale |
LED Qty |
1pcs 8mm round hat 0.24w rgb led with 4pin common anode |
Input Volt |
DC12V |
Max current |
50MA |
Max Power |
0.6W |
Driver method |
Constant current circuit |
Dimension |
12mm diameter(open hole) |
Viewing angle |
100-120degree |
Protection Level |
IP68 |
Certification |
CE and RoHS |
Standard connection |
100pcs nodes per string |
Standard wire length |
100mm(4inches);all BLACK wire 18awg 13.5mm series black waterproof male and female connectors at ends: input end: 0.2m output end:0.2m long female connector with black flat wire |
Housing |
transparent PVC |
Fixed way |
12mm diameter open hole; 12mm*14mm |
Lifespan |
35000 hours |
Warranty |
2 years |
Operation temperature |
-40-50 |
Store temperature |
-50-60 |
